Automatic Powder Coating Equipment GC901S-A

Parameters

- Standard input voltage: 110-220VAC

- Frequency: 50-60Hz

- Standard output voltage(to spay gun): 12V

- Standard output current(to spray gun): 1.2A

- Gun output voltage: 100KV

- Gun output current: 100uA

- Polarity: Negative electrode

- Protection Level: IP54

- Temperature range: -40 ℃-85℃

- Air inlet pressure: 5.5-6bar

- Maximum air consumption: 8.5Nm³/h

- CANBus fieldbus: Not support

- External control(workpiece recognition system): Support

- Metal powder:  Support

- Other polyester powder: Support

- Powder hose length(m): 16

- Powder hose specification ⌀(mm): 12*18

- Powder hose material type: POE with conductive strip

- Maximum powder discharge rate: 420g/min

Characteristics

- Corona Charging Technology;

- Built-in 100kV high performance voltage doubling module, to ensure extremely high powder rate;

- Precision pressure reducing valve, support external control signals, high performance and high reliability;

- Easy to operate and maintain.

What Is an Electrostatic Powder Coating Line?

An Electrostatic Powder Coating Line is an advanced surface finishing system that uses electrostatic charging technology to apply powder coatings onto metal parts. The charged powder particles adhere evenly to grounded workpieces and are then cured in a high-temperature oven, forming a durable, smooth, and attractive finish.

1.A complete Haztek Powder Coating Line typically includes:

Pre-treatment System – cleans, degreases, and prepares the metal surface for coating.

2.Powder Spray Booth – equipped with manual or automatic electrostatic spray guns for uniform powder application.

3.Curing Oven – melts and solidifies the coating to achieve strong adhesion and corrosion resistance.

4.Conveyor & Reciprocator System – ensures continuous and efficient part movement.

5.Intelligent Control System – synchronizes all components for stable, energy-efficient operation.

Haztek's electrostatic powder coating lines deliver high transfer efficiency, minimal powder waste, and long-lasting coating performance, making them ideal for aluminum profiles, automotive parts, home appliances, and metal furniture.

Benefits of Electrostatic Powder Coating Line

An Electrostatic Powder Coating Line offers numerous advantages over traditional wet painting or manual coating methods. Designed for efficiency, sustainability, and superior finish quality, it helps manufacturers achieve higher productivity and lower operational costs.

Key Benefits:

1.High Transfer Efficiency – Electrostatic attraction ensures more powder adheres to the part, reducing material waste.

2.Durable and Uniform Finish – Produces a consistent coating with excellent adhesion, corrosion resistance, and impact strength.

3.Environmentally Friendly – 100% solvent-free process with minimal VOC emissions and recyclable overspray powder.

4.Low Maintenance and Easy Cleaning – Automated systems reduce downtime and simplify color changes.

5.Energy-Efficient Operation – Optimized curing ovens and intelligent control systems lower power consumption.

6.Cost-Effective Production – Less powder waste, reduced labor, and shorter curing times increase overall profitability.

7.Wide Application Range – Suitable for coating aluminum profiles, automotive parts, steel furniture, home appliances, and more.

With Haztek’s automatic electrostatic powder coating solutions, you gain consistent coating quality, long-term reliability, and a cleaner production environment.

Applications of Electrostatic Powder Coating Line

The Electrostatic Powder Coating Line is widely used across multiple industries where metal surfaces require durable, decorative, and corrosion-resistant finishes. Its versatility and efficiency make it an essential production solution for both small workshops and large-scale manufacturing plants.

Main Applications:

1.Aluminum Profiles – Architectural frames, windows, doors, and curtain walls.

2.Automotive Industry – Car rims, chassis parts, bumpers, and accessories.

3.Home Appliances – Refrigerator panels, washing machine drums, and air conditioner housings.

4.Metal Furniture – Office furniture, shelves, cabinets, and outdoor tables and chairs.

5.Electrical and Industrial Equipment – Control boxes, enclosures, lighting fixtures, and machinery parts.

6.Construction and Infrastructure – Guardrails, fences, pipelines, and structural components.

By integrating Haztek’s automatic powder coating systems, manufacturers can achieve consistent coating thickness, improved corrosion protection, and long-lasting color performance across all types of metal substrates.

Why Choose Haztek Powder Coating Line

Choosing Haztek means choosing precision, reliability, and innovation in every detail of your powder coating process. With over 20 years of industry experience, Haztek provides complete electrostatic powder coating solutions — from manual systems to fully automated production lines.

Why Haztek:

1.Professional Engineering Team – Tailor-made designs to meet your specific production layout and coating requirements.

2.Advanced Technology – DVC high-precision powder flow control and intelligent electrostatic systems ensure consistent coating quality.

3.High-Quality Components – All parts are built for durability, stability, and long service life.

4.Turnkey Solutions – From pre-treatment to curing oven, Haztek provides a fully integrated coating line with centralized control.

5.Global Support – Exported to over 30 countries with reliable technical service and fast spare parts supply.

6. Strong R&D Capability – Continuous product upgrades to enhance efficiency, automation, and energy savings.

Haztek is committed to helping manufacturers build a high-performance, energy-efficient, and cost-effective powder coating line that delivers premium surface finishing results every time.
