PINNACLE GC21A Automatic Spray Gun Controller

Intelligent, secure, and stable controller, integrated fault  diagnosis system

Equipped with over 250 programmable coating programs and 3 daily quick programs, it can  quickly switch between different types of coating workpieces, which enhances production  efficiency and reduces consumables. The DVC digital valve technology can precisely control the  powder output. The parameters on the LCD display are clear and easy to understand.  Meanwhile, it supports CANBus fieldbus networking control or standalone control without a  network, and supports the connection of external I/O signals for external control.

DVC Digital Valve Technology / Precise Powder Flow Control

This technology achieves stability and high consistency in the spraying process through the precise regulation of powder output, atomizing air and delivery air.

Key + multi-dimensional incremental knob

Visual operation interface, instant adjustment of various parameters

Press the button and adjust with the multi-dimensional incremental knob, paired with an LED display, parameters are intuitive and clear. The multi-dimensional incremental knob allows for quick adjustment of various parameters. The knob integrates voltage, flow, and current adjustment functions, convenient and quick, with the minimum current adjustment at 1A and the minimum voltage adjustment at 1kV.

Operators only need to simply select the corresponding mode on the control panel during production, one-click call up expert-level spraying parameters, without the need for cumbersome manual adjustment, ensuring stable and efficient spraying quality.

Three Preset Spray Modes (Flat Workpieces, Re-sprayed Workpieces, Special-shaped Workpieces)

250 Programmable Spray Programs, Enabling Repeatable Coating Effects

It can be programmed individually, store 250 custom programs, and these programs can be recalled at any time, ensuring quick and convenient operation.

Stable Performance

Electronic components from world-class brands ensure the stability and maximum performance  of the control unit. The aluminum alloy body features excellent heat dissipation, reducing  malfunctions and extending the equipment's service life.

GCS Spray Gun Control System

A good helper for large-scale spray gun deployment

The GCS Spray Gun Control System is developed based on the x86 platform, featuring excellent  adaptability and scalability. It reserves digital interface APIs and supports access via the  CANBus industrial bus and external I/O signals, facilitating interconnection and  intercommunication with other production equipment (such as robots, automated powder booth  equipment, and production line PLCs) or intelligent systems (such as MES and ERP). This  enables the realization of a highly intelligent coating production process, as well as data  collection and traceability

The system can be expanded to a maximum of 120 spray guns, capable of meeting the needs of  large-scale production, and can be freely combined according to the actual type of workpiece,  providing flexible and customized spraying solutions.

The system can store thousands of spray formulas, ensuring quick access under different  requirements such as workpieces, colors, thicknesses, etc., reducing production changeover  time, and significantly improving production efficiency.

By integrating the MES system, the system can automatically match the optimal coating formula  based on order requirements and workpiece specifications, flexibly adapt to various production  tasks, and achieve true flexible manufacturing.

The built-in self-diagnosis function can monitor the device status in real time, automatically  detect and prompt for faults, ensuring that the device always operates in the best condition and  reduces the risk of downtime due to faults.

The system supports remote monitoring functionality, allowing users to remotely view the  operating status of devices, adjust parameters, and even perform remote maintenance, greatly  enhancing the convenience and efficiency of management.

PINNACLE GC21 equipment parameters

Standard input voltage：100-250VAC

Frequency：50-60 Hz

Standard output voltage (to spray gun)：12 V

Standard output current (to spray gun)：1.2 A

Spray gun output voltage：100kV

Spray gun output current：100μA

Polarity：cathode

Protection level：IP54

Temperature range：-40°C-85°C

Compressed air

Input pressure：5.5-6bar

Maximum air consumption：8.5Nm³/h

Other functions

Canbus fieldbus：Support

External control （workpiecerecognition system）：Support

Powder coating capability

Metal powder capability：yes

Other polyester powder capability：yes

Standard configuration

Powder hose length (m)：4

Powder hose specification Ø (mm)：11*17

Powder hose material type：POE with Conductive Strip

Maximum powder discharge rate：520g/min

What Is an Electrostatic Powder Coating Line?

An Electrostatic Powder Coating Line is an advanced surface finishing system that uses electrostatic charging technology to apply powder coatings onto metal parts. The charged powder particles adhere evenly to grounded workpieces and are then cured in a high-temperature oven, forming a durable, smooth, and attractive finish.

1.A complete Haztek Powder Coating Line typically includes:

Pre-treatment System – cleans, degreases, and prepares the metal surface for coating.

2.Powder Spray Booth – equipped with manual or automatic electrostatic spray guns for uniform powder application.

3.Curing Oven – melts and solidifies the coating to achieve strong adhesion and corrosion resistance.

4.Conveyor & Reciprocator System – ensures continuous and efficient part movement.

5.Intelligent Control System – synchronizes all components for stable, energy-efficient operation.

Haztek's electrostatic powder coating lines deliver high transfer efficiency, minimal powder waste, and long-lasting coating performance, making them ideal for aluminum profiles, automotive parts, home appliances, and metal furniture.

Benefits of Electrostatic Powder Coating Line

An Electrostatic Powder Coating Line offers numerous advantages over traditional wet painting or manual coating methods. Designed for efficiency, sustainability, and superior finish quality, it helps manufacturers achieve higher productivity and lower operational costs.

Key Benefits:

1.High Transfer Efficiency – Electrostatic attraction ensures more powder adheres to the part, reducing material waste.

2.Durable and Uniform Finish – Produces a consistent coating with excellent adhesion, corrosion resistance, and impact strength.

3.Environmentally Friendly – 100% solvent-free process with minimal VOC emissions and recyclable overspray powder.

4.Low Maintenance and Easy Cleaning – Automated systems reduce downtime and simplify color changes.

5.Energy-Efficient Operation – Optimized curing ovens and intelligent control systems lower power consumption.

6.Cost-Effective Production – Less powder waste, reduced labor, and shorter curing times increase overall profitability.

7.Wide Application Range – Suitable for coating aluminum profiles, automotive parts, steel furniture, home appliances, and more.

With Haztek’s automatic electrostatic powder coating solutions, you gain consistent coating quality, long-term reliability, and a cleaner production environment.

Applications of Electrostatic Powder Coating Line

The Electrostatic Powder Coating Line is widely used across multiple industries where metal surfaces require durable, decorative, and corrosion-resistant finishes. Its versatility and efficiency make it an essential production solution for both small workshops and large-scale manufacturing plants.

Main Applications:

1.Aluminum Profiles – Architectural frames, windows, doors, and curtain walls.

2.Automotive Industry – Car rims, chassis parts, bumpers, and accessories.

3.Home Appliances – Refrigerator panels, washing machine drums, and air conditioner housings.

4.Metal Furniture – Office furniture, shelves, cabinets, and outdoor tables and chairs.

5.Electrical and Industrial Equipment – Control boxes, enclosures, lighting fixtures, and machinery parts.

6.Construction and Infrastructure – Guardrails, fences, pipelines, and structural components.

By integrating Haztek’s automatic powder coating systems, manufacturers can achieve consistent coating thickness, improved corrosion protection, and long-lasting color performance across all types of metal substrates.

Why Choose Haztek Powder Coating Line

Choosing Haztek means choosing precision, reliability, and innovation in every detail of your powder coating process. With over 20 years of industry experience, Haztek provides complete electrostatic powder coating solutions — from manual systems to fully automated production lines.

Why Haztek:

1.Professional Engineering Team – Tailor-made designs to meet your specific production layout and coating requirements.

2.Advanced Technology – DVC high-precision powder flow control and intelligent electrostatic systems ensure consistent coating quality.

3.High-Quality Components – All parts are built for durability, stability, and long service life.

4.Turnkey Solutions – From pre-treatment to curing oven, Haztek provides a fully integrated coating line with centralized control.

5.Global Support – Exported to over 30 countries with reliable technical service and fast spare parts supply.

6. Strong R&D Capability – Continuous product upgrades to enhance efficiency, automation, and energy savings.

Haztek is committed to helping manufacturers build a high-performance, energy-efficient, and cost-effective powder coating line that delivers premium surface finishing results every time.
