2-in-1 Manual Powder Coating Booth

Functional Integration: Integrates the "manual electrostatic powder spraying" operation area  with the "powder recovery" system, eliminating the need for additional independent recovery  equipment and saving site space.

Operational Flexibility: Relies on manual operation of the spray gun, suitable for coating small  and medium-sized workpieces, special-shaped parts, or small-batch customized coating needs,  with flexible adjustment of spraying angles and ranges.

Cost Economy: The integrated design reduces equipment procurement costs, and the recovery  system can reuse unadsorbed powder coatings, reducing raw material loss.

Manual Electrostatic Powder Coating Booth（Dimensional Parameters）

External Dimensions：

L14000 × W1300 × H2200 mm

Working Opening：

L880 × W550 × H1300 mm

Affect the operating space of artificial or mechanical spraying，Determine the volume of workpiece that can be accommodated

The recommended maximum size for workpieces is:

L300 × W250× H800 mm

About Size Customization:

1. The work area can be customized according to the size of the workpiece.

2. The fan power is matched according to the size of the work area, with a standard 1.5KW fan.  When the size of the work area increases, adjust the number of fans according to the actual  situation, along with the power and the number of filters.

3. Regarding the air compressor, a normal 220V air compressor with a power of 3180W and a  capacity of 40L is used.

DVC Digital Valve Technology / Precise Powder Flow Control

This technology achieves stability and high consistency in the spraying process through the

precise regulation of powder output, atomizing air and delivery air.

PCC Precision Charging

Dynamic charge regulation and intelligent matching achieve efficient charging and uniform adsorption of powder particles, significantly improving coating quality and production efficiency.

For workpieces with complex geometries (such as automotive wheel hubs and home appliance casings), its charge regulation system can dynamically enhance the electric field intensity in hidden areas like deep cavities and grooves, ensuring the powder adsorption coverage rate is further improved.

250 Programmable Spray Programs, Enabling Repeatable Coating Effects

It can be programmed individually, store 250 custom programs, and these programs can be recalled at any time, ensuring quick and convenient operation.

Manual Powder Spray Gun Mg20

Built-in 100KV high-voltage module, suitable for the majority of common powders; ergonomic  design; spray gun with quick parameter keys

PPH40 Automatic Sprayer Suitable for quick color change and quick cleaning

The product meets the "plug and play" functionality, suitable for quick color changes and quick  cleaning. The quick insertion design of the powder tube facilitates the separation and  connection for cleaning. The Venturi tube is made of high-quality non-stick material and is  equipped with a quick connector for connecting compressed air. The powder supply is stable  and even, with excellent atomization effect, which helps to form high-quality coatings. The  maximum powder output rate can be up to 520g/min (depending on specific configuration and  powder type).

Manual Electrostatic Powder Coating 2 in 1 Booth Equipment Parameters

Standard input voltage：100-240VAC

Frequency：50-60 Hz

Standard output voltage (to spray gun)：12 V

Standard output current (to spray gun)：1.2 A

Spray gun output voltage：100kV

Spray gun output current：100μA

Polarity：cathode

Protection level：IP54

Temperature range：-40°C-85°C

Compressed air

Input pressure：5.5-6bar

Maximum air consumption：8.5Nm³/h

Other functions

Canbus fieldbus：Support

External control （workpiecerecognition system）：Support

Powder coating capability

Standard configuration

Powder hose length (m)：16/20(Standard Powder Hose Options for Automatic Spray Guns)

Powder hose specification Ø (mm)：12*18/11*17

Powder hose material type：POE with Conductive Strip

Maximum powder discharge rate：520g/min

What Is a Powder Coating Booth?

A powder coating booth is an essential part of a modern electrostatic powder coating system, designed to apply dry powder coatings onto metal parts without using any solvent. The coating material is in powder form and is sprayed through an electrostatic spray gun. Charged powder particles adhere to grounded metal surfaces, forming a smooth and durable coating after curing in the oven.

Haztek electrostatic powder coating booths are designed for small to large metal parts, offering excellent flexibility, fast color changes, and high coating efficiency. They are ideal for industries such as home appliances, aluminum profiles, automotive parts, and general metal fabrication.

Benefits of Haztek Electrostatic Powder Coating Booth

Our orbital-type electrostatic powder coating booth is specially designed for internal coating applications such as boilers or water heaters. Its innovative structure allows one operator to handle loading and unloading from a single position, while other parts are coated simultaneously inside the booth — maximizing efficiency and reducing labor costs.

Once coating is completed, the parts can be easily transferred to the overhead conveyor system for curing in the oven.

Key Advantages

1.Compact installation – requires less floor space

2.100% powder recycling – minimizes waste and reduces cost

3.Automated or robotized application – ensures consistent quality

4.Precise film thickness control – uniform coating results

5.No drying required – one less process step

6.Low operating and maintenance cost

7.Minimal manpower – one operator can control the entire process

8.Homogeneous coating quality – stable and repeatable performance

What Is the Function of an Electrostatic Powder Coating Booth?

An electrostatic powder coating booth is an enclosed space designed to contain the powder coating process and ensure a clean, controlled application environment.
A powder recovery system with a powerful fan draws air into the booth, preventing oversprayed powder from escaping while enabling efficient powder collection and recycling.

Haztek powder coating booths can be configured for manual, automatic, or combined applications, depending on production needs. Conveyorized systems allow parts to move continuously through the booth for higher efficiency and consistent coating quality.

Key Features and Design Options

1.Material Options: Booths are commonly made from stainless steel, polypropylene, or polycarbonate for durability, easy cleaning, and improved illumination.

2.Clean & Safe Operation: Non-conductive plastic walls reduce powder buildup, improving transfer efficiency and simplifying maintenance.

3.Flexible Configuration: The size and design of the booth depend on part dimensions, workspace, and production volume.

4.Efficient Airflow: Properly engineered airflow (100–120 lfpm) ensures even powder containment and safe operation below 50% of the LEL (Lower Explosion Limit).

Haztek electrostatic powder coating booths are ideal for coating metal parts of various sizes — from small components to large industrial workpieces — delivering high transfer efficiency, fast color change, and long-term durability.

Everything You Need to Know About Electrostatic Powder Coating Booths

Q: What is the purpose of an electrostatic powder coating booth?

An electrostatic powder coating booth provides a clean, enclosed environment for applying powder coatings. It uses exhaust fans and filters to remove overspray and prevent powder from escaping, ensuring a safe, efficient, and high-quality coating process.

Q: Why are electrostatic powder coating booths white?

White interior panels improve brightness, visibility, and cleanliness, while reducing the risk of cross-contamination between colors.

Q: How do powder coating booths stay clean?

Follow a preventive maintenance schedule.

Replace filters regularly.

Use strippable wall coatings and protective floor coverings.

Keep proper airflow and temperature settings year-round.

Q: How long does a powder coating booth last?

With proper maintenance, a booth can last 20–40 years. Regular cleaning and component upgrades extend its service life.

Q: Can the booth be used for both powder and liquid coatings?

Yes, dual-use booths exist, but they require specialized design. Powder and liquid coatings differ in application methods and equipment requirements.

Q: What causes powder coating booth fires?

Common causes include electrical faults, welding sparks, poor waste handling, or unsafe smoking practices near the booth.

Q: How can I prevent dust in my powder coating booth?

Always keep doors closed and ensure the exhaust system is running to maintain negative pressure and filter out airborne contaminants.

Q: What is the ideal temperature and humidity for coating?

Maintain around 70°F (21°C) and 50% relative humidity for optimal coating adhesion and curing performance.

Q: Why does my powder coat chip easily?

Chipping is usually caused by poor surface preparation or lack of pretreatment. Ensure the substrate is clean, dry, and properly blasted before coating.

Q: Do I need a powder coating booth for powder coating?

Yes. Without a booth, overspray can contaminate other equipment and affect worker safety.

Q: Is fire suppression required?

Yes. All coating booths must meet NFPA fire protection standards and include a fire suppression system.

Q: Does powder coating scratch off easily?

Powder coating is highly durable, but long-term exposure to sunlight, weather, or harsh cleaning chemicals can cause wear. Minor scratches can be repaired by repainting.

Q: How much airflow is required?

Typical airflow is 50–100 FPM, depending on booth size and design, ensuring even powder containment and ventilation.

Q: How large should the exhaust fan be?

Multiply booth height × width × desired air velocity (e.g., 10 ft × 14 ft × 100 FPM = 14,000 CFM).

Q: How can I keep the booth cool?

Maintain proper ventilation, keep doors closed, and use ceiling fans to regulate airflow.

Q: How many coats can you apply in powder coating?

Two coats are common. Pre-gel the first coat at 392°F (200°C) for 2–3 minutes before applying the second layer for best adhesion.

Q: What is the best pressure for powder coating?

Use 5–10 psi for most applications. Lower pressure improves coverage in recessed or Faraday areas.

Q: How do you protect the powder-coated finish?

Use non-abrasive car wax with UV protection to maintain gloss and prevent fading.

Q: How to reduce humidity in the booth?

Install an “all outside air” ventilation system with heating and cooling control to maintain consistent air conditions.

Q: What temperature is required for powder curing?

Powder coatings typically cure at 180–220°C (356–428°F) — higher than most liquid coatings — depending on the powder type.
